สวิตซ์ Huawei รุ่น HW-S220S-24P4J
24 x 10/100/1000BASE-T PoE+ ports，4 x 2.5GE SFP ports | Packet forwarding rate: 51 Mpps | Switching capacity: 68 Gbit/s
11730.00฿
สวิตซ์ Huawei รุ่น HW-S220S-24P4J
24 x 10/100/1000BASE-T PoE+ ports，4 x 2.5GE SFP ports | Packet forwarding rate: 51 Mpps | Switching capacity: 68 Gbit/s
Highlight Features
Offers flexible port options with GE/2.5GE multi-rate electrical ports for access and GE/2.5GE/10GE optical ports for uplink.
Supports ERPS (ITU-T G.8032) technology for millisecond-level protection switching alongside traditional STP and RSTP.
Provides comprehensive security against DoS attacks and user-targeted threats to protect the network.
Features DHCP snooping with a binding table and trusted port settings to prevent unauthorized DHCP server connections.
Includes Perpetual PoE, ensuring uninterrupted power supply to connected devices even during a switch restart or software upgrade.
Supports Smart Upgrade via HOUP with one-click automation and version pre-loading to minimize service interruption and upgrade risks.
Enables cloud management through the HUAWEI eKit App, allowing for remote configuration, monitoring, and lower OPEX.
Allows flexible switching between cloud-based and on-premise management modes to protect investment and support network evolution.
Simplifies O&M with multiple management tools including the HUAWEI eKit App, SNC, and a web-based system.
Download Datasheet
Feature | Specification |
Switching capacity | 68 Gbit/s |
Packet forwarding rate | 51 Mpps |
GE RJ45 | 24 (PoE+) (1G/100M/10M) |
2.5G SFP | 4 (2.5G/1G/100M) |
PoE | Supported |
Maximum PoE power consumption [W] | 400 |
Certification | EMC certification Safety certification Manufacturing certification |
Chassis material | Metal |
Static power consumption [W] | 18.74 |
Dimensions without packaging (H x W x D) | Basic dimensions: 43.6 mm x 442 mm x 220 mm (1.72 in. x 17.40 in. x 8.66 in.) Maximum dimensions: 43.6 mm x 442 mm x 227 mm (1.72 in. x 17.40 in. x 8.94 in.) |
Dimensions with packaging (H x W x D) | 90.0 mm x 550.0 mm x 360.0 mm (3.54 in. x 21.65 in. x 14.17 in.) |
Installation type | Rack mounting, Desk mounting, Wall mounting |
Weight without packaging [kg(lb)] | 2.8 kg (6.17 lb) |
Weight with packaging [kg(lb)] | 3.71 kg (8.18 lb) |
Typical power consumption [W] | 33.32 |
Maximum power consumption [W] | Without PoE: 38.58 W / Full PoE load: 482.55 W (PoE: 400 W) |
Number of fans modules | 2 |
Long-term operating temperature | –5°C to +45°C (23°F to 113°F) at an altitude of 0 to 1800 m (0 to 5905.44 ft.) |
Long-term operating relative humidity | 5% RH to 95% RH, non-condensing |
Power supply mode | AC built-in |
Input voltage range [V] | AC input: 90 V AC to 290 V AC; 45 Hz to 65 Hz / High-voltage DC input: 190 V DC to 290 V DC |
Power supply surge protection [kV] | Differential mode: ±6 kV; common mode: ±6 kV |
Types of fans | Built-in |
Heat dissipation mode | Air cooling for heat dissipation, intelligent fan speed adjustment |
Airflow direction | Air intake from left and front, air exhaustion from right |
